• Input Voltage Range: 18-35V
• Output Voltage: 13.2V
• Under Voltage Shutdown: 14V
• Under Voltage Restart: 18V
• Continuous Output Current: 40A
• DC Connection: Double faston tabs 6.3mm
• Remote on-off: Yes
• Galvanic Isolation: No
• Can be connected in parallel: No
• Protection Category: IP20
• Dimensions: H65 x W88 x D185mm
• Weight (kg): 0.85
• Warranty: 5 Years

Remote on-off connector

The remote on-off eliminates the need for a high current switch in the input wiring. The remote on-off can be operated with a low power switch or by the engine run/stop switch (see manual).

All models with adjustable output can also be used as a battery charger

For example to charge a 12 Volt starter or accessory battery in an otherwise 24V system.

All models with adjustable output can be paralleled to increase output current

Up to five units can be connected in parallel.

Easy to install

Delivery includes four Insulated Fastons Female Crimp 6.3mm (eight Fastons in case of the Orion 24/12-40).

For Low power models: please see Orion-Tr series
